Video Measuring Projector Pro – QualiVMP™ Pro Series

Precision matters when small dimensional deviations lead to scrap, rework, or assembly delays. The QualiVMP™ Pro Series offers a stable granite structure, high-resolution imaging, and software-controlled lighting to accelerate inspections and deliver consistent measurement results in quality control labs and production environments.

Designed as a projector-style video measuring platform, the QualiVMP™ Pro Series enables non-contact dimensional inspection of parts with edges, radii, holes, slots, and profiles. Its granite base and column ensure stability, while a precision motion stage provides repeatable positioning for accurate measurements.

A zoom optics and digital camera system captures sharp, detailed images for dependable feature recognition. Adjustable LED surface and contour illumination enhances contrast across different materials and finishes, allowing operators to complete inspections more efficiently with minimal measurement errors.

Video Measuring Projector Pro – QualiVMP™ Pro Series Applications

Machined Metal Parts (CNC Turning & Milling)
Check hole locations, widths, chamfers, fillets, and step dimensions without contacting the surface, reducing inspection time for tight-tolerance features.

Stamping and Sheet-Metal Components
Measure outer profiles, slot geometry, and edge conditions. Adjustable lighting enhances edge detection on reflective or brushed surfaces.

Injection-Molded Plastic Components
Verify ribs, bosses, snap-fit features, and part outlines. Non-contact measurement prevents deformation of delicate plastic parts.

Electronics and Precision Assemblies
Inspect connectors, small brackets, and precision housings. Fast go/no-go checks and accurate dimensional measurement support consistent production.

Tooling, Fixtures, and Prototypes
Facilitate first-article inspections and engineering evaluations with quick setup, sharp imaging, and repeatable stage positioning.

Standards

The QualiVMP™ Pro Series meets widely recognized metrology standards to ensure reliable, accurate measurements:

ISO 10360-7 – Acceptance and reverification tests for coordinate measuring machines (CMMs) using imaging or video probing systems.
ISO 14253-1 – Guidelines for verifying conformity and nonconformity while accounting for measurement uncertainty.
ISO 14978 – General concepts and requirements for geometric product specification (GPS) measuring equipment.
ASME B89.4.1 – Performance evaluation methods for coordinate measuring machines, commonly used in dimensional metrology programs.

Video Measuring Projector Pro – QualiVMP™ Pro Series Key Features

Granite Base and Column for Stability
Rigid granite construction ensures stable measurement conditions and consistent performance for daily quality control operations.

Precision Stage Motion with Minimal Return Error
Smooth motion components and a fast-locking mechanism provide repeatable positioning, reducing measurement variation during inspections.

High-Resolution Imaging for Accurate Feature Capture
Zoom optics combined with a digital camera deliver sharp, low-distortion images, enabling precise edge and contour measurements.

Advanced LED Lighting for Optimal Contrast
Multi-zone surface and contour illumination allow quick adjustments for different materials and finishes, improving measurement clarity.

Integrated Vision Measurement Software
iMeasuring software supports geometric measurements, analysis, and reporting, streamlining quality control workflows.

Expandable Sensor Options
Optional touch probes and 3D measurement capability extend functionality beyond non-contact inspections. Autofocus upgrades are also available for semi-automatic workflows.

Video Measuring Projector Pro – QualiVMP™ Pro Series Technical Specifications

Specifications (All Models)

Specification	QualiVMP™ Pro 150 Series	QualiVMP™ Pro 200 Series	QualiVMP™ Pro 250 Series	QualiVMP™ Pro 300 Series	QualiVMP™ Pro 400 Series	QualiVMP™ Pro 500 Series
X/Y Travel (mm)	150 × 100	200 × 100	250 × 150	300 × 200	400 × 300	500 × 400
Z Travel (mm)	100		200
Linear Scale Resolution	0.5 μm (all models)
Guide System	High-precision P-class linear guide (all models)
Accuracy* (E1x,y)	≤ 2.5 + L/200 (μm)		≤ 3.0 + L/200 (μm)
Accuracy* (E1z)	—		≤ 5 + L/200 (μm)
Illumination (software controlled)	8-division LED surface illumination + contour LED parallel illumination + optional coaxial light
Camera	1/2.9" high-resolution digital camera, 1.3 Mpixel (all models)
Zoom Lens	6.5× manual zoom; optical magnification 0.7×–4.5× (all models)
Measuring Software	iMeasuring
Supported OS	Windows 10/11 (32/64-bit)
Languages	English, Simplified Chinese, Traditional Chinese (other languages optional)
Operating Conditions	20°C ±2°C; temperature change <1°C/hr; 30–80% RH; vibration <0.02 g, ≤15 Hz
Power	AC 220V / 50Hz; or 110V / 60Hz
Net Weight	About 200–500 kg (varies by model)

* L = measured length (mm).

Configuration Options

Category	Sensor Package	Model	Type	Sensor Description	Z-Axis Autofocus	Contact Probe	Software	Operation
Manual Video Measuring System	2D	QualiVMP™ Pro 300 Series	—	Optical zoom-lens sensor	Without	Without	iMeasuring 2.0	Manual
Manual Video Measuring System	2.5D	QualiVMP™ Pro 300A Series	A	Optical zoom-lens sensor	Without	Without	iMeasuring 2.1	Manual
Manual Video Measuring System	3D	QualiVMP™ Pro 300B Series	B	Zoom-lens sensor + contact probe sensor	Without	With	iMeasuring 3.1	Manual
Semi-auto Video Measuring System	2.5D	QualiVMP™ Pro 300C Series	C	Zoom-lens sensor + Z-axis autofocus	With	Without	iMeasuring 2.2	Semi-auto
Semi-auto Video Measuring System	3D	QualiVMP™ Pro 300D Series	D	Zoom-lens sensor + contact probe + autofocus	With	With	iMeasuring 3.1	Semi-auto

Measuring Range (Travel) and Z-Axis Customization

Travel Class (X × Y × Z, mm)	Model	Accuracy (E1x,y)	Accuracy (E1z)	X (mm)	Y (mm)	Standard Z (mm)	Max Custom Z (mm)
150 × 100 × 100	QualiVMP™ Pro 150 Series	2.5 + L/200	—	150	100	100	×
200 × 100 × 100	QualiVMP™ Pro 200 Series	2.5 + L/200	—	200	100	100	×
250 × 150 × 200	QualiVMP™ Pro 250 Series	3.0 + L/200	5.0 + L/200	250	150	200	300
300 × 200 × 200	QualiVMP™ Pro 300 Series	3.0 + L/200	5.0 + L/200	300	200	200	300
400 × 300 × 200	QualiVMP™ Pro 400 Series	3.0 + L/200	5.0 + L/200	400	300	200	300
500 × 400 × 200	QualiVMP™ Pro 500 Series	3.0 + L/200	5.0 + L/200	500	400	200	400
