The Story
Electronic Densimeter - MD-300S
For material engineers and lab managers who require unwavering confidence in their data, the Densimeter MD-300S provides the necessary metrological assurance. Its 0.001g/cm³ resolution is engineered not just for measurement, but for the critical detection of subtle batch-to-batch variations that can compromise product performance. This level of precision is vital for validating high performance polymers and other critical materials where process drift is not an option. The rapid ten second test cycle maximizes lab throughput, delivering the data you need without creating bottlenecks in your quality assurance workflow.
The electronic densimeter MD 300S is designed for seamless integration into a modern, data-driven lab environment. Test results are captured reliably via the RS-232C interface, eliminating transcription errors and preserving the integrity of your SPC or LIMS data. Advanced functions, including a comparator mode for immediate pass/fail analysis and a setting mode for new material R&D, move beyond simple measurement to become a core part of your process optimization toolkit. The Densimeter MD-300S is the definitive instrument for when your material characterization must be both fast and fundamentally correct.
Features of the MD-300S Densimeter:
- Popular model with resolution of 0.001g/cm3. (Upgraded from previous model MD-200S)
- Compact body and accurate density measurement for solid and liquid samples.
SOLID MODE:
- Minimum density and volume resolution 0.001g/cm3.
- Maximum measuring range up to 300g.
- Smoother and easier operation with redesigned vessel that features chemical resistant Styrol technology.
- Only 10 seconds to complete a test.
- Able to measure the rate change of density and volume.
- Results can be analyzed with Comparator mode.
- Optional Setting mode is available for unknown samples or new material development.
- Easy connection to PC with equipped RS232 interface.
LIQUID MODE: (Optional kit required)
- Able to measure compensated liquid density.
Specification of Densimeter - MD-300S Densimeter
| Product Name | Densimeter MD-300S |
| Resolution | 0.001g/cm3 |
| Capacity | 0.01-300g |
| Sample Types | Solid, Liquid |
| Weight | 1.6kg |
| Dimensions | (L)218 X (W)190 X (H)170mm |
| Accessories | Tweezers, Thermometer, 200g Calibration Weight, Steel Angle, AC Adapter, RS232 interface, Airtight windshield |
Click Here to visit the product webpage
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
Electronic Densimeter - MD-300S
For material engineers and lab managers who require unwavering confidence in their data, the Densimeter MD-300S provides the necessary metrological assurance. Its 0.001g/cm³ resolution is engineered not just for measurement, but for the critical detection of subtle batch-to-batch variations that can compromise product performance. This level of precision is vital for validating high performance polymers and other critical materials where process drift is not an option. The rapid ten second test cycle maximizes lab throughput, delivering the data you need without creating bottlenecks in your quality assurance workflow.
The electronic densimeter MD 300S is designed for seamless integration into a modern, data-driven lab environment. Test results are captured reliably via the RS-232C interface, eliminating transcription errors and preserving the integrity of your SPC or LIMS data. Advanced functions, including a comparator mode for immediate pass/fail analysis and a setting mode for new material R&D, move beyond simple measurement to become a core part of your process optimization toolkit. The Densimeter MD-300S is the definitive instrument for when your material characterization must be both fast and fundamentally correct.
Features of the MD-300S Densimeter:
- Popular model with resolution of 0.001g/cm3. (Upgraded from previous model MD-200S)
- Compact body and accurate density measurement for solid and liquid samples.
SOLID MODE:
- Minimum density and volume resolution 0.001g/cm3.
- Maximum measuring range up to 300g.
- Smoother and easier operation with redesigned vessel that features chemical resistant Styrol technology.
- Only 10 seconds to complete a test.
- Able to measure the rate change of density and volume.
- Results can be analyzed with Comparator mode.
- Optional Setting mode is available for unknown samples or new material development.
- Easy connection to PC with equipped RS232 interface.
LIQUID MODE: (Optional kit required)
- Able to measure compensated liquid density.
Specification of Densimeter - MD-300S Densimeter
| Product Name | Densimeter MD-300S |
| Resolution | 0.001g/cm3 |
| Capacity | 0.01-300g |
| Sample Types | Solid, Liquid |
| Weight | 1.6kg |
| Dimensions | (L)218 X (W)190 X (H)170mm |
| Accessories | Tweezers, Thermometer, 200g Calibration Weight, Steel Angle, AC Adapter, RS232 interface, Airtight windshield |
Click Here to visit the product webpage
